From the heart of Manila’s industrial landscape, Diaz Sheetsandplates has built a reputation for reliability and expertise in the metal supply industry. We take pride in being your trusted partner for high-grade materials, including the robust Stainless Steel 253Ma Angle. Our focus is on providing not just a product, but a dependable solution backed by deep technical knowledge and a commitment to supporting the growth of various sectors across the Philippines with quality that you can build upon.
The strength of 253Ma begins with its unique composition, which includes a careful balance of chromium, nickel, and nitrogen, along with additions of silicon and cerium. This specialized formula gives it superior resistance to scaling at high temperatures. Mechanically, this translates to an angle that offers excellent creep strength and toughness, allowing it to perform reliably under intense thermal stress and heavy loads where other steels might fail, making it a truly high-performance alloy.
| Standard | ASTM A240 / ASME SA240 |
| Width | 1000mm-2000mm |
| Thickness | 1.0mm – 100mm |
| Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| % | Ni | Cr | Fe | Si | Mn | C | P | N | S | Ce |
|---|---|---|---|---|---|---|---|---|---|---|
| Min | 10 | 20 | Balance | 1.40 | – | 0.05 | – | 0.14 | – | 0.03 |
| Max | 12 | 22 | – | 2 | 0.80 | 0.10 | 0.04 | 0.20 | 0.03 | 0.08 |
| Mechanical Properties | 100⁰C | 900⁰C | 50⁰C | 300⁰C | 200⁰C | 400⁰C | 600⁰C | 500⁰C | 800⁰C | 700⁰C | 850⁰C |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength/ MPa | 621.9 | 171 | 663.3 | 568.1 | 577.8 | 549.5 | 475.7 | 522 | 388.9 | 386.1 | 254.4 |
| 0.2% Yield Strength / MPa | 271 | 80 | 304.8 | 202 | 222 | 200.6 | 166.9 | 173.1 | 148.2 | 158.6 | 100.7 |
| Reduction of area / % | 48 | – | 51 | 46 | 46 | 46 | 43 | 44 | – | 44 | – |
| Elongation / % | 65 | 92 | 68 | 64 | 65 | 60 | 63 | 62 | 76 | 58 | 88 |
| STANDARD | UNS | WERKSTOFF NR. |
| 253 MA | S30815 | 1.4835 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Diaz Sheets and Plates based in Manila, Philippines, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 253MA angle provides excellent resistance to high temperature oxidation and corrosion, making it ideal for use in harsh environments. It maintains its strength and durability at high temperatures, ensuring long-term performance in heat exchangers, furnaces and chemical equipment The alloy is resistant to sulfide stress breakdown and creep, and provides reliable performance at petrochemical and power generation industries. Its weldability and formability make it easy to assemble, while its scaling and corrosion resistance ensure extended working life and reduced maintenance costs.
This exceptional durability makes the 253Ma Angle an ideal choice for some of the most demanding environments. You’ll find it forming the structural backbone of high-temperature industrial furnaces, critical components in power generation plants, and essential parts within petrochemical processing systems. Its ability to withstand oxidation and corrosion at extreme heat also makes it perfect for use in heat exchangers, boiler components, and any framework that must remain stable and strong while constantly exposed to fiery conditions.
