Welcome to Diaz Sheetsandplates, your trusted partner in Manila for premium metal solutions. We take pride in supplying and manufacturing Monel 400 Coil, a material chosen for its exceptional reliability in the most demanding environments. Sourced with care and backed by our local expertise, we ensure you receive a product that meets the highest standards of quality and performance, right here in the Philippines.
Monel 400 is a nickel-copper alloy renowned for its strength. It maintains excellent mechanical properties, including good tensile strength and impressive toughness, even under sub-zero temperatures. This coil form offers outstanding resistance to a wide range of corrosive elements, from saltwater and alkaline solutions to reducing chemicals, making it a consistently durable choice.
Specifications : ASTM B127 / ASME SB127
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled (HR), Cold rolled coils (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Coils, Shim Coils, Strip
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel 400 coil/slitting coil offers excellent corrosion resistance, particularly in acidic environments, making it ideal for marine, chemical, and oil industries. Even at elevated temperatures, it provides high strength, toughness, and durability. The material’s resistance to pitting and stress-corrosion cracking ensures long-term reliability. Its ease of fabrication and weldability make it suitable for various applications, offering versatility in industrial processes. Monel 400 coil/slitting coil is an excellent choice for demanding environments due to its superior mechanical properties and corrosion resistance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
The versatility of Monel 400 Coil makes it indispensable across many industries. You’ll find it forming critical components in marine engineering, such as pump shafts and propeller blades, where saltwater resistance is paramount. It’s equally vital in chemical processing plants for handling corrosive fluids, in oil and gas extraction equipment, and even in specialized musical instruments, proving its value wherever toughness and corrosion resistance are non-negotiable.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
