In the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as a trusted partner for robust metal solutions. We take pride in producing and supplying high carbon steel plates, engineered for projects where failure is not an option. Our commitment extends beyond mere supply; we focus on delivering exceptional strength and durability, plate by plate. For clients across the Philippines who demand reliability in the most challenging applications, our high carbon steel offers the unwavering performance needed to build with confidence and ensure lasting integrity.
The composition of high carbon steel is defined by its higher carbon content, typically ranging from 0.6% to 1.0%, which is the primary source of its remarkable strength. This specific formulation gives these plates superior hardness and impressive resistance to wear and abrasion, though it does make them less malleable than their lower-carbon counterparts. After careful heat treatment, these plates achieve exceptional mechanical properties, including a very high tensile strength and yield point. This makes them ideally suited for tasks that involve significant impact, constant friction, or heavy, sustained loading.
Standard : ASTM A830/ASME SA830
Thickness : 2mm – 600mm
Width : 1000mm – 3000mm
Length : 3000mm – 12000mm
| Grade | C(%)min-max | Si(%)min-max | Mn(%)min-max | P(%)max | S(%)max | Cr(%)min-max |
| C45 | 0.42-0.50 | 0.15-0.35 | 0.50-0.80 | 0.025 | 0.025 | 0.20-0.40 |
| Grade | Condition | Yield Strengtd R°(Mpa) | Tensile Strength Rm (Mpa) | Elon- gation A5(%) | Hardness HRC | Quenching Temperature (℃) | Benda- bility | Nominal Thickness,t 1.95mm≤t≤10.0mm | |
| Rolled | Annealed | ||||||||
| C45 | Rolled Annealed Water-quenched Oil quenched | 460 330 | 750 540 2270 1980 | 18 30 | 58 55 | 820 860 | Min.reco-mmended Bending radius (≤90°) | 2.0 ×t | 1.0×t |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
High Carbon Steel Plates offer several key advantages, including exceptional strength and hardness, making them ideal for heavy-duty applications. Their high tensile strength and wear resistance ensure durability in challenging environments, such as construction, mining, and manufacturing. These plates are highly resistant to abrasion and deformation, providing long-lasting performance. Despite their high hardness, they retain good machinability, allowing for precise cutting and shaping. High Carbon Steel Plates are cost-effective, offering superior value for industries requiring high-strength materials, and are ideal for applications that demand toughness and reliability.
Yes, we offer custom sizes for High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| C45 EN 10083-2 Number:1.0503 | Comparison of steel grades | |
| JIS G 4051 | S 45 C | |
| DIN 17200 | C 45 | |
| NFA 33-101 | AF65-C 45 | |
| UNI 7846 | C 45 | |
| BS 970 | 070 M 46 | |
| UNE 36011 | C 45 k | |
| SAE J 403-AISI | 1042/1045 | |
The exceptional hardness and durability of high carbon steel plates make them indispensable in heavy industry. You’ll commonly find them used as wear liners in mining equipment, crusher jaws, and for heavy-duty cutting tools and blades that must maintain a sharp edge. They are the material of choice for constructing high-strength components like springs, railway tracks, and critical parts for agricultural machinery and earth-moving equipment. Essentially, any application that faces extreme abrasion, intense impact, or requires a formidable level of strength is a perfect match for the resilience of high carbon steel.
