Welcome to Diaz Sheetsandplates, your trusted partner in Manila for robust and reliable steel solutions. We take pride in manufacturing and supplying premium C50 High Carbon Steel sheets and plates, crafted to meet the rigorous demands of various industries right here in the Philippines. Our commitment is to deliver not just a product, but a foundation of strength and durability for your most ambitious projects, ensuring you have a local source for quality you can count on.
C50 steel is defined by its specific composition, primarily consisting of a higher carbon content around 0.50%, which is key to its performance. This formulation gives the material its notable hardness and impressive tensile strength. While it is less malleable than lower-carbon steels, it can be effectively heat-treated through processes like quenching and tempering. This allows for precise adjustments to its final mechanical properties, tailoring it for applications where exceptional wear resistance and the ability to hold a sharp edge are critical.
| Thickness Range | 0.10 – 5.00 MM |
| Width Range | 5.00 – 1250 MM |
| Form | Can be supplied in Coil or Sheet form |
| Sheet Length (CTL) | 300 – 3000 MM |
| Edge | Mill edge or Sheared edge |
| Coil / Sheet Pallet Weight | Weight of each Coil or Sheet pallet can be customized as per customer’s need |
| Coil ID / OD | ID or OD of each Coil can be customized as per customer’s need |
| Packing | High-end export packing for sea or road travel, completely safe during transit. Duly oiled with anti-rust oil, wrapped in hessian cloth & high-density plastic sheets to prevent moisture. Further strapped with high tensile strips. For identification & tracing, non-erasable polyester stickers are placed on each material |
| Delivery Time | Dispatched within 10 days to 2 months, depends upon the required size |
| Some Applications | Auto components such as Washers, Clutch components, various types of Springs, Pen Clips, Hanger Clips, Cycle/Motor Chains, etc. |
Element |
C |
Si |
Mn |
P |
S |
Cr |
Cu |
Ni |
Content (%) |
0.47 – 0.55 |
0.17 – 0.37 |
0.50 – 0.80 |
0.03 |
0.03 |
0.15 |
0.25 |
0.30 |
GRADE |
Tensile Strength min |
Yield Strength min |
Elongation min. |
contraction min |
impact min |
Hardness Max |
|
σb/M Pa |
σs/M Pa |
δ5/% |
ψ/% |
Akv/J |
Without heating |
annealing |
|
C50 |
630 |
375 |
14 |
40 |
31 |
241 |
207 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
C50 High Carbon Steel Plates offer numerous advantages, including superior strength and hardness, making them ideal for heavy-duty industrial applications. Their high tensile and yield strength ensure excellent load-bearing capacity, while their wear resistance provides durability in demanding environments. C50 plates also offer good machinability, allowing for easy fabrication and customization for specific applications. The steel’s exceptional toughness and ability to withstand high-stress conditions make it perfect for use in components like gears, shafts, and machinery. Additionally, C50 High Carbon Steel Plates are cost-effective, providing long-lasting performance and reliability.
Yes, we offer custom sizes for C50 High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| SAE / AISI – American | SAE 1050 |
| DIN – Germany | C50 / CK50 |
| EN – English / BS – British | – |
| JIS – Japanese | S50C |
| UNI – Italy | C50 |
The exceptional strength of C50 High Carbon Steel makes it the material of choice for a wide array of heavy-duty applications. You will commonly find it used in the fabrication of high-strength components like gears, shafts, and heavy-duty springs that endure constant stress. It is also indispensable in the tooling industry for creating durable blades, punches, and dies. Beyond machinery, its properties are leveraged in construction for structural parts and in agriculture for manufacturing resilient tillage tools and cutter bars.
