Diaz Sheetsandplates is a renowned manufacturer and supplier of Zirconium Sheets and Plates in Manila, Philippines, delivering high-quality, precision-engineered products trusted across various industries. Our Zirconium Sheets and Plates are crafted using advanced production techniques to ensure superior corrosion resistance, exceptional strength, and excellent thermal stability. Known for their remarkable performance in highly corrosive environments, these products are ideal for industries such as chemical processing, nuclear power, and marine engineering. At Diaz Sheetsandplates, we are committed to offering dependable materials that meet global standards and ensure efficiency, reliability, and longevity in every application.
Zirconium sheets and plates are primarily composed of zirconium metal, with purity levels typically exceeding 99.5%. They may contain small amounts of alloying elements such as tin, iron, and chromium to enhance specific properties. Zirconium is highly resistant to corrosion, especially in aggressive environments like acids and seawater. Its mechanical properties include excellent strength, toughness, and flexibility at both high and low temperatures. It has a high melting point (1855°C), good fatigue resistance, and low thermal expansion, making it ideal for applications in aerospace, nuclear, and chemical industries.
| Standard Specification : | ASTM B551 / ASME SB551 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Zirconium and Zirconium Alloys Chemical Composition | |||||||||
| Products | Chemical Composition (wt%≤) | ||||||||
| Sn | Fe | Ni | Cr | Fe+Cr | Fe+Ni+Cr | Nb | Al | B | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.005 | 0.15 | 0.0070 | 0.02 | – | – | – | 0.0075 | 0.0005 |
| R60802 (Zr-2) | 1.20-1.70 | 0.07-0.20 | 0.03-0.08 | 0.05-0.15 | – | 0.18-0.38 | – | 0.0075 | 0.0005 |
| R60804 (Zr-4) | 1.20-1.70 | 0.18-0.24 | 0.0070 | 0.07-0.13 | 0.28-0.37 | – | – | 0.0075 | 0.0005 |
| R60901 (Zr-2.5Nb) | 0.0050 | 0.150 | 0.0070 | 0.02 | – | – | 2.4-2.8 | 0.0075 | 0.0005 |
| R60904 (Zr-2.5Nb) | 0.010 | 0.065 | 0.0035 | 0.01 | – | – | 2.5-2.8 | 0.0075 | 0.0005 |
| Zirconium and Zirconium Alloys Sheet & Plate Mechanical Properties | |||||
| Grades | |||||
| Products | R60700 | R60702 | R60704 | R60705 | R60706 |
| Tensile strength, min, ksi (MPa) | – | 55 (380) | 60 (415) | 80 (550) | 74 (510) |
| Yield strength, min, ksi (MPa) | – | 30 (205) | 35 (240) | 55 (380) | 50 (345) |
| Tensile strength, max, ksi (MPa) | 55 (380) | – | – | – | – |
| Yield strength, max, ksi (MPa) Sheet, Plate and Strip | 44 (305) | – | – | – | – |
| Elongation in 2 in. or 50 mm, min, % | 20 | 16 | 14 | 16 | 14 |
| Bend test radius | 5T | 5T | 5T | 3T | 2.5T |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Zirconium Sheets and Plates are primarily composed of high-purity zirconium (Zr) with trace amounts of hafnium and other elements to enhance their mechanical stability. They exhibit excellent corrosion resistance, particularly against strong acids such as hydrochloric and sulfuric acid. Zirconium also has a high melting point (approximately 1855°C), tensile strength between 330–580 MPa, and outstanding ductility, allowing easy fabrication and welding. The material maintains its mechanical integrity even at elevated temperatures, making it suitable for high-performance and long-term applications in harsh industrial environments.
Zirconium Sheets and Plates are widely used in chemical processing plants, nuclear reactors, and aerospace components due to their excellent corrosion resistance and heat tolerance. In the chemical industry, they are ideal for fabricating heat exchangers, reactor vessels, and evaporators that handle aggressive chemicals. The nuclear sector values zirconium for its low neutron absorption, making it perfect for cladding fuel rods. Additionally, it finds applications in marine environments, pharmaceutical equipment, and medical implants. With unmatched durability and purity, Zirconium Sheets and Plates are the material of choice for industries demanding top-tier performance and reliability.
Yes, we offer custom sizes for Zirconium Sheets and Plates to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Zirconium sheets and plates are widely used in industries requiring high corrosion resistance and durability. They are essential in nuclear reactors for fuel cladding due to their low neutron absorption. In the chemical industry, they are used for reactors, pipes, and valves exposed to aggressive acids. Zirconium’s biocompatibility makes it valuable in medical implants and dental applications. Additionally, it is used in aerospace for high-temperature components, as well as in military applications for its strength and resistance to harsh environments. These sheets and plates also find use in electronics and energy production.
