Diaz Sheetsandplates stands as a trusted name in Manila, providing industry-leading materials to the Philippine market. We specialize in supplying high-performance Rene 41 sheets and plates, a superalloy known for its exceptional strength under extreme conditions. Our commitment is to deliver not just a product, but a reliable solution, backed by deep expertise and a focus on supporting the ambitious engineering projects that drive progress across the nation. We are your dedicated partner for materials that demand uncompromising performance.
The remarkable strength of Rene 41 comes from a sophisticated nickel-chromium composition, further enhanced by significant cobalt and molybdenum content. This unique blend allows it to retain impressive tensile and creep strength at temperatures that would cause most metals to fail. Even after exposure to intense heat, it maintains excellent hardness and resistance to oxidation. Essentially, it’s engineered to perform reliably in the most demanding thermal environments, making it a cornerstone material for advanced aerospace and industrial applications.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Diaz Sheets and Plates based in Manila, Philippines, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Rene 41 sheets and plates offer numerous advantages, making them a preferred choice for demanding applications. They provide exceptional strength and durability, maintaining integrity under extreme temperatures and high-stress conditions. Their superior heat resistance and oxidation protection ensure long-lasting performance in environments exceeding 980°C (1800°F). With excellent corrosion resistance, Rene 41 is ideal for aerospace, power generation, and automotive industries. Its outstanding weldability and machinability enable precise fabrication for complex components. These properties make Rene 41 sheets and plates a reliable and versatile solution for critical, high-performance applications.
Yes, we offer custom sizes for Rene 41 Sheets and Plates to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
You’ll find Rene 41 sheets and plates at the heart of innovation, particularly in the aerospace sector where they are essential for components like turbine blades, exhaust systems, and other hot-section parts of jet engines. Its capabilities also extend to critical applications in chemical processing equipment and high-temperature tooling. Any industry that pushes the boundaries of heat and stress, from power generation to advanced racing engines, relies on the unparalleled performance of this superalloy to ensure safety, efficiency, and durability.
