In the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as a trusted partner for robust marine and chemical processing solutions. We take pride in manufacturing and supplying the exceptional Monel 400 Channel, a product born from our commitment to quality and durability. Sourced and processed with meticulous care, our channels are designed to meet the demanding challenges of corrosive environments, offering reliability that our clients in the Philippines and beyond have depended on for years.
The strength of Monel 400 lies in its unique composition, primarily a blend of nickel and copper, which gives it a natural resistance to seawater and many corrosive chemicals. This alloy maintains excellent mechanical properties, including good tensile strength and impressive toughness, even in sub-zero temperatures. It doesn’t become brittle and retains its structural integrity, making it a remarkably reliable material for challenging engineering applications where failure is not an option.
| Specifications | : | ASTM B164 / ASME B164 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Monel 400 Channel | : | 40mm*20mm~300mm*300mm |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | C Channel, U Channel, Channels |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | Cu | Fe | Ni | S |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 28.00 – 34.00 | 2.50 max | 63.00 min | 0.024 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35000 , MPa – 240 | 40% |
Monel 400 Channel offers numerous advantages, including excellent corrosion resistance in marine and chemical environments, making it ideal for harsh conditions. Its high tensile and yield strength ensure durability and reliability under mechanical stress. The alloys resistance to acidic and alkaline substances enhances its versatility in diverse industrial applications. Monel 400 exhibits excellent thermal conductivity and stability, performing well in high-temperature environments. Additionally, it resists stress corrosion cracking and pitting, ensuring a long service life. Its machinability and weldability further simplify fabrication and installation processes.
Yes, we offer custom sizes for Monel 400 Channel to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| STANDARD | MATERIAL NO. | US | HE | GOST | BS | AFNOR | IN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | MNJMc 28-2.5-1.5 | THAT 13 | NO-30M | NiCu30Fe |
You’ll find Monel 400 Channels hard at work in some of the most demanding settings. They are essential in marine engineering for constructing boat shafts, pumps, and fasteners that constantly battle saltwater corrosion. In chemical plants, they form the framework for processing equipment handling acids and alkalis. Beyond that, these channels are also valued in oil and gas extraction, aerospace components, and even specialized architectural features where long-term resilience against the elements is absolutely critical.
