In the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as your trusted partner for high-performance materials. We specialize in supplying top-quality Duplex Steel S32205 sheets and plates, bringing exceptional strength and corrosion resistance directly to the Philippine market. Our dedication lies in providing reliable solutions for the nation’s most demanding projects, ensuring that our clients have access to world-class materials backed by local expertise and a commitment to service that is both responsive and dependable.
This remarkable Duplex Steel, known as S32205 or 2205, gets its strength from a balanced austenitic-ferritic microstructure. Its composition, rich in chromium, nickel, molybdenum, and nitrogen, delivers a fantastic combination of toughness and resistance. This material offers a high tensile strength, excellent resistance to stress corrosion cracking, and maintains good ductility and impact strength, making it a robust choice where ordinary steels would fail.
| Specification | ASTM A 815, ASME SA 815, ASTM A 182, ASME SA 182 |
| Type | Seamless / Welded / Fabricated |
| Range | ½”NB to 24″NB in Sch 10S, 40S, 80S, 160s, XXS |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| S32205 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheet and Plates S32205 offer a combination of high strength and excellent corrosion resistance, making them ideal for harsh environments. Their balanced microstructure of austenite and ferrite enhances resistance to stress corrosion cracking, pitting, and crevice corrosion. With superior mechanical properties, including high tensile strength and yield strength, S32205 is highly durable and reliable. These plates also offer excellent weldability and formability, making them versatile for various industrial applications such as chemical processing, offshore, and marine industries. They provide a cost-effective alternative to more expensive high-alloy steels in demanding conditions.
Yes, we offer custom sizes for Duplex Steel Sheet and Plates S32205 to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Duplex 2205 | UNS S31803 | 1.4462 | F51 |
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
The unique properties of Duplex S32205 sheets and plates make them invaluable across a wide spectrum of industries. They are extensively used in chemical processing and offshore oil and gas equipment where resistance to harsh, corrosive environments is non-negotiable. You’ll also find them in desalination plants, pulp and paper production, and in the construction of storage tanks and pressure vessels. Essentially, wherever a project demands longevity and resilience against aggressive chemicals and seawater, this material proves to be an outstanding and cost-effective solution.
