For over two decades, Diaz Sheetsandplates has been a cornerstone of Manila’s industrial supply, building a reputation for reliability that extends across the Philippines. We take pride in supplying top-tier materials to the nation’s growing industries, and our Alloy 20 Steel Angle is a prime example of this commitment. Known for its exceptional resistance to corrosive environments, this alloy is a go-to choice for engineers and fabricators who demand durability and long-term performance in their most challenging projects, making it a trusted component in building a stronger industrial future.
The strength of Alloy 20 Steel Angle comes from its unique composition, which includes a significant amount of nickel and chromium, enhanced with copper and molybdenum. This specific blend gives it outstanding mechanical properties, offering a remarkable tensile strength and excellent yield strength that stands up to heavy loads. More importantly, it’s this carefully balanced formula that grants the alloy its superb resistance to sulfuric acid and other aggressive chemicals, making it not just strong, but incredibly resilient in harsh conditions where ordinary steels would quickly fail.
Specifications : ASTM B473, B464, B468 / ASME SB473, SB464, SB468
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
| Grade | C | Mn | Si | S | P | Fe | Ni | Cr | Mo | Cu |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 0.045 max | 29.85 min | 32.00 – 38.00 | 19.00 – 21.00 | 2.00 – 3.00 | 3.00 – 4.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Diaz Sheets and Plates based in Manila, Philippines, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Alloy 20 Steel Angle offers several key advantages, making it ideal for challenging industrial applications. Its superior corrosion resistance, especially against sulfuric acid and chloride environments, ensures long-lasting durability in chemical, petrochemical, and pharmaceutical industries. The alloy’s high tensile strength and excellent resistance to pitting, stress corrosion, and crevice corrosion make it highly reliable in extreme conditions. Additionally, Alloy 20 exhibits good weldability and formability, allowing for easy fabrication and versatile use. These properties make it an ideal choice for structural applications where reliability and resistance to harsh conditions are essential.
Yes, we offer custom sizes for Alloy 20 Steel Angle to meet specific project needs. Our team at Diaz Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
You’ll find Alloy 20 Steel Angle hard at work in some of the most demanding settings. It’s essential in constructing chemical processing plants, pharmaceutical manufacturing equipment, and food processing machinery where resistance to corrosion is non-negotiable. Fabricators value it for building robust frames, supportive structures, and custom brackets for tanks and reactors. Its reliability also makes it a preferred material in components for marine and offshore applications, ensuring structural integrity where exposure to saltwater and other corrosive elements is a constant challenge.
