In the heart of Manila’s industrial landscape, Diaz Sheetsandplates stands as a trusted partner for high-performance materials. We take pride in supplying and manufacturing top-tier A286 sheets and plates, providing local industries with a reliable source for this exceptional superalloy. Our commitment is to deliver not just a product, but a solution built on quality and dependable service, ensuring your projects have the robust foundation they need to succeed in the most demanding environments.
The strength of A286 lies in its unique composition, primarily iron-nickel-chromium, enhanced with additions of molybdenum, titanium, and aluminum. This sophisticated recipe gives the material its remarkable mechanical properties, including exceptional tensile strength and impressive resistance to creep at elevated temperatures. It maintains this toughness and corrosion resistance even under intense heat, making it far more capable than standard stainless steels for challenging applications.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
A286 sheets and plates provide exceptional strength and resistance to oxidation and corrosion, making them ideal for high temperature applications. They maintain their mechanical properties at temperatures up to 1300°F (704°C), making them suitable for gas turbines, jet engines, and chemical processing The alloy’s excellent formability makes it easy to manufacture, while its excellent weldability ensures a strong and durable joint . A286 is also stress and corrosion resistant, making it more reliable in harsh environments. These advantages make it a desirable material for aerospace, marine, and industrial applications.
| STANDARD | WERKSTOFF NR. | UNS |
| A286 | 1.4980 | S66286 |
You’ll find A286 sheets and plates hard at work in sectors where failure is not an option. They are essential in aerospace for turbine engines and structural components, and in industrial settings for high-temperature fixtures and turbine parts. This superalloy is also crucial for fasteners in demanding environments and within automotive engines, proving its versatility and reliability wherever extreme heat and stress are part of the daily equation.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
